CH230-L100.2

0-60 mph in just 3.1 seconds acceleration

Linear actuator, 125 N, AC 100…240 V, Open/close, 3-point, 380 s, Stroke 100 mm, IP54 Multipack 20 pcs

Description

Voltage AC/DC

AC 100…240 V

Power consumption (running)

1.5 W

Power consumption (holding)

1 W

Power Consumption For Wire Sizing

3 VA

Connection Supply Control

Cable 1 m, 3x 0.75 mm²

Force

125 N

Control type

Direction Of Motion Motor

by electrical installation

Manual override

With magnet

Stroke

100 mm

Running time (motor)

380 s / 100 mm

Protection category

IP54

Degree Of Protection NEMA

NEMA 2

Enclosure Type

UL Enclosure Type 2

Ambient Temperature

-30…50°C [-22…122°F]
